G15-L3-0048
Door kit MAGNA² P&L 2700 mm · flat-pack · 2 locks
Aluminium
Rear door kit MAGNA² in aluminium, opening of 2700 mm, four bi-fold leaves, supplied FLAT-PACK with locking system P&L of 2 locks included. Reducible by 200 mm (100 at the top, 100 at the bottom). 134,5 kg. No certification declared.
Specifications
- Dimensions
- HT 2700 (opening) · HD 2746 (door) · L 2.490 (door width) · 2.550 (outer corner = overall vehicle width)
- Weight
- 134,5 kg
- Position
- Symmetrical part / not handed
- Vehicle area
- Rear
- Technical data
- Door MAGNA² bi-fold, FLAT-PACK, in aluminium, for trailers and semi-trailers. LOCKING SYSTEM P&L with 2 LOCKS. Corner piece («joint corner») which gives the 2.550 outside width. End dimension/base 23 mm. REDUCIBLE KIT 200 mm (100 at the top + 100 at the bottom) — twice that of the Knock and the sKin. The WEIGHT SHOWS HOW MUCH THE LOCKS WEIGH: in the same HT 2.400 A MAGNA² weighs 104 kg without locks, 122 with 2 THIRIET and 140 with 4 — 18 kg per PAIR of locks THIRIET and 18,25 kg per pair P&L.
Identification
- Supplier reference
- AT.4.0.2700.0.P2
- Brand
- Takler
- Type
- Kit
P&L LOCKING SYSTEM WITH 2 LOCKS — not interchangeable with the other system or with a different number of locks.
